Is your construction site being dragged down by these problems?

The space of the venue is extremely narrow, and all large mixing equipment cannot enter the site.

Indoor floor paving, corridor repair, villa courtyard hardening, the width of the passage into the old community is less than 1 meter, and the width of the fuselage of conventional mixers and small diesel mixing equipment is generally more than 1.5 meters, which is completely impassable. They can only rely on manual shoveling and mixing. The labor cost is high, and the daily pouring volume is extremely low.

Micro-pouring demand, double waste of materials and fuel for large-scale mixing equipment

House repair, floor cushion layer, and small foundation only need 0.1-0.2m³ concrete at a time. After the large mixing tank is started, the raw material consumption is high, and the idle fuel loss is large. The remaining concrete cannot be stored and directly scrapped, and the long-term comprehensive cost of construction is high.

The ratio of manual mixing is uncontrollable, and the concrete strength is insufficient and the rework is frequent.

Manually mixed sand, stone, cement and clear water with experience, the ratio error is extremely large, and the molding floor and wall are easy to crack and leak. Secondary rework requires additional procurement of raw materials and labor payment to compress all profits of the project.

The procurement investment of split construction equipment is high, and the narrow site cannot be placed at the same time.

Purchase loaders, small mixing barrels and transshipment trolleys separately. The total purchase price of multiple sets of equipment is higher, and the scattered equipment occupies a small construction space, and the material transshipment process leaks and dust pollutes the site.

Micro-construction projects are scattered, and the transfer of heavy equipment requires trailers to increase freight.

The points of decoration and courtyard transformation projects are scattered. Large-scale mixing equipment has high self-weight and large size. Trailers must be leased for cross-community and cross-courtyard transfer. The accumulation of short-distance transshipment freight is a considerable implicit expense.

Disassembly of the whole machine structure and quality details

Original Bailitong gasoline powertrain

The whole machine is equipped with a regular channel Bailitong 13.5 horsepower gasoline engine, and comes with complete EPA and Euro5 emission certification documents from the factory. The power output is stable, the fuel consumption is low, and the low-temperature ambient electricity starts smoothly. Most of the low-priced mini machines on the market use unqualified miscellaneous engines, and no emission certification cannot be exported. In Europe and the United States, the power decay is fast, the failure rate is high, and frequent downtimes affect the construction progress.

Three sets of independent all-hydraulic drive systems

Loading, stirring and dumping are equipped with independent hydraulic cylinders and hydraulic pipelines respectively. The integrated sealed oil line anti-leakage design, and continuous stirring for a long time does not have the problem of lifting weakness and stuck oil leakage; simple competitive products adopt single oil line mechanical transmission, and the action is synchronous and uncontrollable. The operation of unloading and loading in a small space is not flexible, and short-term use Hydraulic failure is easy to occur.

Thickened wear-resistant sealed mixing barrel

The total volume of the mixing barrel is 0.3m³, the barrel body is thickened and wear-resistant steel plate is integrally molded, and the internal wear-resistant stirring blades are added, and the rolling and stirring is uniform without dead angle; the sealed barrel body design, the indoor stirring sand and stone, cement is not scattered everywhere, suitable for closed shops, indoor decoration construction environment, single accurate output 0.2m³ Concrete, which fully matches the micro-construction needs.

Lightweight and stable frame

The frame of the whole vehicle is welded and molded by thickened load-bearing steel plate, and the welds are intact. The net weight of the whole machine is controlled by 750kg, taking into account the light transition and heavy load stability; the width of the whole machine is compressed to 900mm, which is specially designed for the optimization structure of the door, corridor and courtyard passage. The frame is all sandblasted and anti-rust spraying, and the coastal tide Long-term use on wet construction sites is not easy to rust and deform.

How does the Mini Self-Loading Concrete Mixer work?

Step 1: Drive to the material pile – drive next to the raw materials

The operator presses the electric start button, ignites and starts the 13.5-horsepower gasoline engine with one click, and drives the equipment to the sand and stone pile or cement storage area at the construction site. No need to connect electricity – the gasoline engine is independently driven and completely detached from the power grid.

Step 2: Automatic loading – Hydraulic bucket “eat” material

The front hydraulic loading bucket of the equipment is lowered, pushed forward, and shoveled up – the sand and gravel aggregate is loaded into the bucket. Then the hydraulic system raises the bucket and pours the material into the feed port of the mixing cylinder at the top of the equipment. The whole process is completed by an operator through the hydraulic joystick, and no ground assistance is required. The capacity of the 750L bucket is about 0.5-0.6m³, and about 4-5 buckets need to be loaded to fill a batch.

Step 3: Ingredients – Accurate feeding of capacity scale

After the raw materials enter the mixing cylinder, the operator refers to the capacity scale mark on the mixing barrel to accurately control the amount of cement and water according to the mixing ratio. It does not rely on the experience of workers to judge – the capacity scale makes every feeding available.

Step 4: Stirring – Hydraulic drive, mix evenly

After all the raw materials enter the mixing cylinder, the hydraulic motor drives the mixing cylinder to start rotating. The spiral stirring blade inside the mixing cylinder lifts the material from the bottom of the cylinder to the top and then drops it during rotation, and stirs repeatedly. The stirring time for a single batch is 3-5 minutes.

Step 5: Unloading – Hydraulic bucket, one-click dumping

After the mixing is completed, the operator controls the hydraulic bucket system – the mixing barrel is overturned and dumped, and the concrete is accurately unloaded to the target position. The whole process is completed by one person, and no additional manual handling is required.

Four core value advantages

Bailitong original gasoline power, EPA+Euro5 double compliance, unimpeded construction sites

Most of the similar micro-mixing equipment on the market uses mixed-brand gasoline engines, which do not have complete emission certification. Exports to Europe and the United States cannot be cleared and are intercepted when entering the market. This machine is equipped with an imported Bailitong 13.5-horsepower electric start engine, and a full set of EPA American environmental protection certification and Euro5 EU emission test reports are provided with the goods. , export customs clearance is worry-free, and small and micro construction sites in residential areas, indoors and urban areas can be built in compliance, completely avoiding the risk of diesel equipment prohibition and fines. Micro-consultation guidance: WhatsApp contact sales and send the complete certificate PDF of EPA and Euro5 certification.

Fully hydraulic three-system integrated design, fully automatic operation for one person in a narrow field

The loading, mixing and unloading of the whole machine all rely on independent hydraulic drive. There is no cumbersome mechanical chain and gear structure, and the failure rate is much lower than that of simple mechanical mini mixing equipment. The 900mm extreme narrow fuselage is suitable for all kinds of narrow channels in the room. Only one operator is needed to complete all processes, and there is no need to hire additional shovels and transshipment. Workers, greatly reduce overseas high labor expenses; a single accurate output of 0.2m³ concrete, mix on demand, and completely eliminate the loss of scrapping of surplus materials purchased by commercial mixed vehicles. Micro-consultation guidance: provide daily pouring frequency, free measurement of annual labor + raw material cost saving.

2500×900×1500mm ultra-compact and lightweight fuselage, no transportation cost for transfer

The length, width and height of the whole machine are only 2.5m×0.9m×1.5m. The width of the conventional self-loading mixer on the market is generally more than 1.5m, which cannot enter the indoor space; the net weight and load of the machine are 750kg, and a single person can easily move. There is no need to rent a trailer to go back and forth at multiple project points in the community and courtyard. , save long-term short-distance transshipment freight; the overall equipment occupies a very small area, indoor construction will not take up too much operation space, and the placement of materials and personnel activities are more relaxed. Micro-consultation guidance: Provide the actual width of the gate and corridor of your construction site, and the engineer will confirm the suitability of traffic.

Strict quality control of the whole machine in the source factory, and a full set of export supporting services without invisible consumption

As a 750L mini mixing equipment professional source factory, there is no intermediary branding and price increase, and the quotation of the same configuration is much lower than that of overseas local dealers; each equipment completes the no-load and full-load cycle mixing test before leaving the factory, and the whole process detection of hydraulic system and gasoline power, with thickened wear-resistant mixing barrels, sealed and leak-proof Oil road, coastal rainy, high temperature environment is stable and durable; shipment synchronously supporting CE, ISO, emission certification, packing list, certificate of origin full set of customs clearance documents, support English operation manual, online video technical training, long-term supply of global accessories. Micro consultation guidance: request a live video of the full-load test of the 750L model from the factory.

Mini Self-Loading vs Ordinary Self-Loading Mixer: How to choose?

Frequently asked questions

1.Are you a real production factory or a trade intermediary for the mini mixer?

Answer: We have our own exclusive assembly workshop and emission testing workstation for micro mixing equipment. The model is the core self-developed main product of our factory. We can independently complete the whole machine assembly, engine debugging, and full-load factory testing. There is no branded sub-production. We can send real-time videos of workshop production and support customers to make appointments for on-site factory inspection.

2.Does the mini mixer meet the EPA and Euro5 environmental protection requirements of the construction sites in the United States and the European Union, and can it be cleared smoothly?

Answer: Each device is equipped with the original Bailitong 13.5 horsepower gasoline engine, and the factory comes with a complete EPA American environmental protection certification and an Euro5 EU emission test report. The whole set of qualification documents can be used for customs clearance and site environmental protection security inspection, and there are no compliance obstacles for exports in Europe and the United States.

3.750L model mixing bucket 0.3m³, how much concrete can actually be mixed each time, and are the parameters false?

Answer: The total volume of the mixing barrel is 300dm³ (0.3m³), and the factory’s full-load actual measurement is 0.2m³ for a single stable and effective discharge. All dimensions, volume and load parameters are actual measurement data. There is no false labeling in the industry, and the actual measurement video check of the discharge can be provided.

4. The width of the whole machine is 900mm. Can ordinary indoor doors and community corridors pass smoothly?

Answer: The narrowest width of the whole machine is only 900mm, and the conventional indoor door, the gate of the villa courtyard, and the corridor of the community can be directly passed through. If the width of your site passage is special, the actual size can be provided, and the engineer will evaluate the traffic adaptation plan.

5. 5. Is it difficult to operate the whole machine? How long will it take for novice workers to master the complete workflow?

Answer: The design of the hydraulic operation handle of the whole machine is simplified, with exclusive Chinese and English operation videos and instructions for the 750L model. Zero basic workers can independently complete the full set of processes of loading, stirring and unloading in half a day; online after-sales service provides maintenance and operation guidance at any time.

6. Compared with conventional large self-feed mixers, how can I judge whether it is suitable for purchasing the 750L mini model?

Answer: If your main business is interior decoration, courtyard renovation, small and micro-projects in residential areas, small single pouring volume, local restricted diesel equipment, narrow construction channels, 750L mini-machine is the best choice; if your main business is large-area infrastructure construction in the field, bulk construction in rural areas, open site without environmental protection control, it is suitable for large-scale self-up loading and mixing. The car can tell you of your business type, and the engineer will recommend it accurately.

750L Mini Self-Loading Concrete Mixers Technical Data
