Items |
Units |
Models and parameters |
HBT40S-10-45 |
HBT50S-12-55 |
HBT60S-13-90 |
HBT60S-16-110 |
HBT80S-13-110 |
HBT80S-16-132 |
Performance
of the
machine |
Theoretical max. discharging volume |
m³/h |
40 |
50 |
60 |
60 |
80 |
80 |
Theoretical max. delivery pressure |
Mpa |
10 |
12 |
12.5 |
15.7 |
12.5 |
15.7 |
Max. delivery frequency |
times/min |
24 |
20 |
22(low pressure)
13(high pressure) |
22(low pressure);13(high pressure) |
26(low pressure); 16(high pressure) |
26(low pressure); 16(high pressure) |
Theoretical max. delivery distance |
Vertical |
m |
120 |
150 |
180 |
250 |
180 |
250 |
Horizontal |
m |
300 |
350 |
700 |
1000 |
700 |
1000 |
Distribution valve type |
|
S valve |
S valve |
S valve |
S valve |
|
|
Specification of delivery cylinder |
mm |
Φ160×1000 |
Φ200×1200 |
Φ200×1650 |
Φ200×1650(1800) |
Φ200×1650 |
Φ200×1650(1800) |
Specification of main oil cylinder |
mm |
Φ100/Φ70×1000 |
Φ125/Φ80×1200 |
Φ125/Φ80×1650 |
Φ140/Φ90×1650(1800) |
Φ125/Φ80×1650 |
Φ140/Φ90×1650(1800) |
Oil tank capacity |
L |
300 |
300 |
420 |
420 |
420 |
420 |
Hopper capacity |
L |
600 |
600 |
600 |
600 |
600 |
600 |
Feeding height |
mm |
1400 |
1400 |
1400 |
1400 |
1400 |
1400 |
Outlet opening diameter |
mm |
Φ125 |
Φ150 |
Φ150 |
Φ150 |
Φ150 |
Φ150 |
Inner dia. of delivery pipe |
mm |
Φ125 |
Φ125 |
Φ125 |
Φ125 |
Φ125 |
Φ125 |
Power
system |
Main motor power |
Kw |
45 |
55 |
90 |
110 |
110 |
132 |
Rated voltage |
V |
380 |
380 |
380 |
380 |
380 |
380 |
Rated speed |
r/min |
1480 |
1480 |
1480 |
1480 |
1480 |
1480 |
Hydraulic
system |
Hydraulic oil circuit type |
|
Open circuit |
Open circuit |
Open circuit |
Open circuit |
Open circuit |
Open circuit |
Max. oil pressure of pumping system |
MPa |
28 |
28 |
32 |
32 |
32 |
32 |
Max. oil pressure of mixing system |
MPa |
14 |
14 |
14 |
14 |
14 |
16 |
Max. mixing speed |
r/min |
30 |
24 |
24 |
24 |
24 |
24 |
Other
parameters |
Allowed range of concrete slump |
mm |
80~200 |
80~200 |
80~200 |
80~200 |
80~200 |
80~200 |
Max. diameter of aggregates |
mm |
Pebble 40,Crushed stone 30 |
Pebble 40,crushed stone 30 |
Pebble 50,crushed stone40 |
Pebble 50,crushed stone40 |
Pebble 50, crushed stone40 |
Pebble 50, crushed stone 40 |
Dimension
(length ×width ×height) |
mm |
4970×1680×2580 |
5270×2000×1840 |
6170×1800×2100 |
6170×1800×2100 |
6170×1930×2100 |
6170×1930×2100 |
Overall weight |
Kg |
3200 |
3500 |
5100 |
5200 |
5200 |
5500 |
Pulling speed |
Km/h |
≤8 |
≤8 |
≤8 |
≤8 |
≤8 |
≤8 |
