Diesel-engine Concrete Mixer with Pump
EP diesel-engine concrete mixer with Pump is a highly efficient and versatile construction equipment that combines the functions of a concrete mixer and a concrete pump.The concrete mixer with Pump is designed to provide better mixing quality and faster pumping speed than traditional methods.
Production Types
Mixer Types
Name:
Diesel-engine Concrete Mixer with Pump
Theoretical output (m3/h):
30/40
Power type:
Diesel
Share With:
Diesel-engine Concrete Mixer with Pump
Features
Technical Info
Inquiry
Diesel-engine Concrete Mixer with Pump
Diesel-engine Concrete Mixer with Pump
Diesel-engine Concrete Mixer with Pump
Diesel-engine Concrete Mixer with Pump
Diesel-engine Concrete Mixer with Pump
Diesel-engine Concrete Mixer with Pump
Diesel-engine Concrete Mixer with Pump
  • Diesel Concrete Mixer with Pump Hydraulic System: Hydraulic system has safe relief protection,at the same time,when the system pressure is over, the main oil pump cutting device makes itself be protected reliably.
  • Diesel-engine Concrete Mixer with Pump Mechanical System: The design of hopper and S valve and so on adopt I-DEAS software to calculate, the hopper and S valve have good rigidity to avoid the phenomenon of hopper distortion and S valve breakage.
  • Diesel Concrete Mixer Pump Lubrication System: The hydraulic circuit will take high oil into double distributor,and then the lubricating part can obtain hydraulic oil.It prolongs the life of piston and other sealings.
  • Diesel-engine Concrete Mixer Pump Cooling System: The radiator equipment makes the working oil temperature of hydraulic system below 70℃ and makes the machine in normal status.
Diesel-engine Concrete Mixer with Pump
Item DJBT30-JZC350 DJBT40A-JZC450
Theoretical output (m3/h) 30 40
Max. concrete pumping pressure (MPa) 10 10
Power type Diesel engine Diesel engine
Main oil pump Jinda Kawasaki
Concrete cylinder diameter x stroke (mm) Φ140×1000 Φ180×1000
Main oil cylinder diameter x stroke (mm) Φ80×1000 Φ100×1000
Theoretical delivery distance (m) 120/400 140/500
Hopper capacity (L) 550 550
Max. aggregate diameter (mm) 20 30/40
Inside diameter of delivery pipe (mm) Φ100 Φ125
Loading capacity of the mixer (L) 560 720
Unloading capacity of the mixer (L) 350 450
Mixing motor (kw) 5.5 5.5
Hoisting motor (kw) 4.5 4.5
Dimension: length x width x height 6000x2300x3150 6000x2100x2800
Total weight(kg) 5000 6000
--> -->
